53317**
Size and weight
| Ød | 85 mm |
| ØD | 150 mm |
| H | 53.1 mm |
| H₁ | 58 mm |
| C | 17.5 mm |
| R | 112 mm |
| rₛ | 1.5 mm |
| Ød₁ | 150 mm |
| ØD₁ | 88 mm |
| ØD₂ | 115 mm |
| ØD₃ | 155 mm |
| s | 43 mm |
| Mass | 4.35 kg |
Data on related components
| dₐ | min. 124 mm |
| Dₐ | max. 115 mm |
| rₐ | max. 1.5 mm |
| Appropriate sphered washer | U317 ~ |
Data for calculation
| Basic dynamic load rating | Cₐ | 227.46 kN |
| Basic static load rating | C₀ₐ | 517 kN |
| Fatigue load limit | Cᵤ | 21.68 kN |
| Reference speed - grease | nG | 1300 min⁻¹ |
| Reference speed - oil | nₒ | 1800 min⁻¹ |
| Minimum load factor | M | 1.2 ~ |
** indicates bearing in NEW FORCE standard
