24136CK30W33J
Size and weight
| Ød | 180 mm |
| ØD | 300 mm |
| B | 118 mm |
| rₛ | 3 mm |
| a | 6 mm |
| b | 11.1 mm |
| Mass | 31.9 kg |
Data on related components
| dₐ | min. - mm |
| Dₐ | max. 286 mm |
| rₐ | max. 2.5 mm |
| Appropriate adapter sleeve | - ~ |
| Appropriate withdrawal sleeve | AH24136 ~ |
| Appropriate withdrawal nut | KM38 ~ |
Data for calculation
| Basic dynamic load rating | Cᵣ | 1250 kN |
| Basic static load rating | C₀ᵣ | 2400 kN |
| Fatigue load limit | Cᵤ | 224.9 kN |
| Reference speed - grease | nG | 850 min⁻¹ |
| Calculation factor | e | 0.37 ~ |
| Calculation factor | Y1 | 1.8 ~ |
| Calculation factor | Y2 | 2.7 ~ |
| Calculation factor | Y₀ | 1.8 |
** indicates bearing in NEW FORCE standard
